Traxxas Unlimited Desert Racer (UDR) with LED Set - BLUE
The Traxxas Unlimited Desert Racer (UDR) is engineered on an true to scale fourwheel drive desert race truck chassis. The 4-link solid rear axle design provides massive suspension travel with true authentic driving dynamics.
With the UDR, Traxxas is introducing a new Traxxas innovation called Pro-Scale that captures true-scale realism and combines it with extreme 6s LiPo power and 80+ kph performance. The Traxxas Unlimited Desert Racer faithfully captures the look and feel of Trophy Trucks and Unlimited Trick Trucks as they charge hard across the desert at full speed.
UDR Specifications:
Length: 694 mm
Front Track: 345 mm
Rear Track: 345 mm
Ground Clearance: 58 mm
Weight: 6.1 kg
Height: 261 mm
Wheelbase: 420 mm
Front Shock Length: 134 mm
Front Threaded Shock Length: 134 mm
Rear Shock Length: 160 mm
Rear Threaded Shock Length: 139 mm
Tires (pre-glued): 134 x 57 mm BFGoodrich® KR3 replicas
Wheels: dual diameter 40 x 56/81 mm
Speed Control: Velineon® VXL-6s
Motor (electric): 2200kV
Transmission: Direct-drive with Torque-Biasing Center Drive
Overall Drive Ratio: 17.89:1
Front Differential Type: Sealed, 4-gear
Rear Differential Type: Locked spool
Center Differential Type: Sealed, 4-gear (1M weight oil)
Chassis Structure / Material: Inverted composite tub
Brake Type: Electronic
Drive System: Shaft driven 4WD
Steering: Dual bellcranks with ball bearings
Radio System: TQi? 2-channel transmitter with 6533 TSM receiver
Servo: 2075X Metal Gear
Top Speed (stock gearing): 4s LiPo 48+ kph, 6s LiPo 80+ kph
Skill Level: 5
Battery Compartment: 181 x 46 x 56 mm
Motor specifications:
Type: Sensorless brushless
Weight: 406 g
Length: 76 mm
Diameter: 42 mm
Connector Type: Traxxas 6.5 mm bullet connectors
ESC Specifications:
Input Voltage (cells): 4s 6s LiPo (max: 25.2 volts)
Case Size: 58 x 48 x 29 mm
Weight: 121 g
On-Resistance (@Trans) - Fwd/Rev: 0.0003 Ohms per phase
Reverse Delay: Yes, with lockout
Low Voltage Detection (LVD): Yes, programmable
What s In The Box:
Unlimited Desert Racer with VXL-6s ESC and 2200kV motor
Quick Start Guide
TQi? 2.4GHz radio system
High quality maintenance tools
What You ll Need:
Batteries
Unlimited Desert Racer accepts a single 4s LiPo battery or dual 2s LiPo batteries or dual 3s LiPo batteries
Charger
Traxxas EZ-Peak Live charger (2971) is recommended for easy and fast charging performance
Four AA alkaline batteries for the transmitter
Specifications:
Car Type: Short Course
Delivered as: RTR (Ready-To-Run)
Drive: 4WD
Operating Mode: Electric
Scale: 1/7
Suitable For: Experienced, Expert
Length: 694 mm
Ground Clearence: 58 mm
Height: 261 mm
Weight: 6100 g
Width: 345 mm
ESC: Traxxas Velineon VXL-6s
Top Speed: 50km/h with 4S Li-Po, 80km/h with 2x3S Li-Po (Optional)
Transmitter: Traxxas TQi 2,4GHz
Motor Type: Brushless
Motor/Engine: Traxxas Velineon 2200kV
Battery: Not Included
Charger: Not Included
Water Proof: Yes
Also Including: LED Set
Needed To Complete: 2x 3s LiPo or 1x 4s LiPo Batteries, 4 AA Transmitter Batteries, iD Charger
PRODUCT WITH SPECIAL DELIVERY TIME (3-7 working days in Spain)
